Basic Decoding of a SEL Record
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
6 Intel order number G90620-002 Revision 1.1
Byte Field Description
[6:0] – Event Type Codes
01h = Threshold (States = 0x00-0x0b)
02h-0ch = Discrete
6Fh = Sensor-Specific
70-7Fh = OEM
14 Event Data 1
(ED1) Per Table 2
15 Event Data 2
(ED2)
16 Event Data 3
(ED3)
