System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Processor Subsystem
Revision 1.1 Intel order number G90620-002 61
6.2 Catastrophic Error Sensor
When the Catastrophic Error signal (CATERR#) stays asserted, it is a sign that something serious has gone wrong in the hardware.
The BMC monitors this signal and reports when it stays asserted.
Table 49: Catastrophic Error Sensor Typical Characteristics
Byte Field Description
11 Sensor Type 07h = Processor
12 Sensor Number 80h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 03h (Digital Discrete)
14 Event Data 1 [7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset = 1h (State Asserted)
15 Event Data 2 Event Data 2 values as described in Table 50.
16 Event Data 3 Bitmap of the CPU that causes the system CATERR.
[0]: CPU1
[1]: CPU2
[2]: CPU3
[3]: CPU4
Note: If more than one bit is set, the BMC cannot
determine the source of the CATERR.
Table 50: Catastrophic Error Sensor – Event Data 2 Values – Next Steps
ED2 Description Next Steps
00h Unknown
1. Cross test the processors.
2. Replace the processors depending on the results of the test.
