System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 15
Sensor
Number
Sensor Name Details Section Next Steps
18h
PCI Riser 4 Temperature
(PCI Riser 4 Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
19h
Baseboard +1.05V Processor3
Vccp
(BB +1.05Vccp P3)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
1Ah
Baseboard +1.05V Processor4
Vccp
(BB +1.05Vccp P4)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
20h
Baseboard Temperature 1
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
21h
Front Panel Temperature
(Front Panel Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
22h
SSB Temperature
(SSB Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
23h
Baseboard Temperature 2
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
24h
Baseboard Temperature 3
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
25h
Baseboard Temperature 4
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
26h
IO Module Temperature
(I/O Mod Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
27h
PCI Riser 1 Temperature
(PCI Riser 1 Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
28h
IO Riser Temperature
(IO Riser Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
29h –2Bh
Hot-Swap Back Plane 1-3
Temperature
(HSBP 1-3 Temp)
HSC Backplane Temperature
Sensor
Table 88: HSC Backplane Temperature Sensor – Event Trigger Offset –
Next Steps
