Manageability Engine (ME) Events
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
118 Intel order number G90620-002 Revision 1.1
13.3 Node Manager Health Event
A Node Manager Health Event message provides a runtime error indication about Intel ® Intelligent Power Node Manager’s health.
Types of service that can send an error are defined as follows:
 Misconfigured policy Error reading power data
 Error reading inlet temperature
Table 95: Node Manager Health Event Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 002Ch or 602Ch – ME Firmware
11 Sensor Type DCh = OEM
12 Sensor Number 19h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 73h (OEM)
14 Event Data 1 [7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Health Event Type = 02h (Sensor Node Manager)
15 Event Data 2 [7:4] – Error type
0-9 – Reserved
10 – Policy Misconfiguration
11 – Power Sensor Reading Failure
12 – Inlet Temperature Reading Failure
13 – Host Communication error
14 – Real-time clock synchronization failure
15 – Platform shutdown initiated by NM policy due to execution of action defined by Policy Exception Action
[3:0] – Domain Id
16 Event Data 3 If Error type = 10 or 15
