System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Processor Subsystem
Revision 1.1 Intel order number G90620-002 69
Table 57: Processor MSID Mismatch Sensor Typical Characteristics
Byte Field Description
11 Sensor Type 07h = Processor
12 Sensor Number 81h = Processor 1 MSID Mismatch
87h = Processor 2 MSID Mismatch
88h = Processor 3 MSID Mismatch
89h = Processor 4 MSID Mismatch
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 03h ( “digital” discrete)
14 Event Data 1 [7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset = 1h (State Asserted)
15 Event Data 2 Not used
16 Event Data 3 Not used
6.6.1 Processor MSID Mismatch Sensor – Next Steps
Verify the processor is supported by your baseboard. Check your boards Technical Product Specification (TPS).
