Cooling Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
54 Intel order number G90620-002 Revision 1.1
Byte Field Description
7Ah = Processor 3 Thermal Control %
7Bh = Processor 4 Thermal Control %
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 01h (Threshold)
14 Event Data 1 [7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Triggers as described in Table 42
15 Event Data 2 Reading that triggered event
16 Event Data 3 Threshold value that triggered event
Table 42: Processor Thermal Control Sensors Event Triggers – Description
Event Trigger Assertion
Severity
Deassert
Severity
Description
Hex Description
07h
Upper non-critical
going high
Degraded OK The thermal margin has gone over its upper non-critical threshold.
09h
Upper critical
going high
non-fatal Degraded The thermal margin has gone over its upper critical threshold.
5.2.3.1 Processor Thermal Control % Sensors – Next Steps
These events normally occur due to failures of the thermal solution:
1. Verify heatsink is properly attached and has thermal grease.
2. If the system has a heatsink fan, ensure the fan is spinning.
3. Check all system fans are operating properly.
4. Check that the air used to cool the system is within limits (typically 35°C).
