System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Power Subsystems
Revision 1.1 Intel order number G90620-002 41
4.4.2 Power Supply Power In Sensors
These sensors will log an event when a power supply in the system is exceeding its AC power in threshold.
Table 22: Power Supply Power In Sensors Typical Characteristics
Byte Field Description
11 Sensor Type 0Bh = Other Units
12 Sensor Number 54h = Power Supply 1 Status
55h = Power Supply 2 Status
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 01h(Threshold)
14 Event Data 1 [7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Trigger Offset as described in Table 23
15 Event Data 2 Reading that triggered event
16 Event Data 3 Threshold value that triggered event
The following table describes the severity of each of the event triggers for both assertion and deassertion.
Table 23: Power Supply Power In Sensor – Event Trigger Offset – Next Steps
Event Trigger Offset Assertion
Severity
Deassert
Severity
Description Next Steps
Hex Description
07h Upper non-critical
going high Degraded OK PMBus* feature to monitor power
supply power consumption. If you see this event, the system is pulling too much power on the
input for the PSU rating.
1. Verify the power budget is within the specified range.
2. Check http://www.intel.com/p/en_US/support/ for the
power budget tool for your system.
09h Upper critical
going high non-fatal Degraded
