System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Power Subsystems
Revision 1.1 Intel order number G90620-002 35
Table 15: Power Unit Status Sensors Typical Characteristics
Byte Field Description
11 Sensor Type 09h = Power Unit
12 Sensor Number 01h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1 [7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] = Sensor Specific offset as described in Table 16
15 Event Data 2 Not used
16 Event Data 3 Not used
Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next Steps
Sensor Specific Offset Description Next Steps
Hex Description
00h Power down System is powered down. Informational Event
02h 240 VA power down 240 VA power limit was exceeded and the
hardware forced a power down. This could have been caused by many things.
1. If you recently added hardware, try removing it.
2. Remove/replace any add-in adapters.
3. Remove/replace the power supply.
4. Remove/replace the processors, DIMM, and/or hard drives.
5. Remove/replace the boards in the system.
04h A/C Lost A/C power was removed. Informational Event
