System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 25
Sensor
Number
Sensor Name Details Section Next Steps
06h
Intel ® Quick Path Interface
Correctable Error
QPI Correctable Error Sensor QPI Correctable Error Sensor – Next Steps
07h Intel ® Quick Path Interface Fatal Error QPI Fatal Error and Fatal Error #2 QPI Fatal Error and Fatal Error #2 – Next Steps
11h Sparing Redundancy State Sparing Redundancy State Sparing Redundancy State Sensor – Next Steps
13h Memory Parity Error Memory Address Parity Error Memory Address Parity Error Sensor – Next Steps
14h
PCI Express* Fatal Error#2
(continuation of Sensor 04h)
PCI Express* Fatal Errors and Fatal Error #2
PCI Express* Fatal Error and Fatal Error #2 Sensor – Next
Steps
17h
Intel ® Quick Path Interface Fatal Error
#2
(continuation of Sensor 07h) QPI Fatal Error and Fatal Error #2 QPI Fatal Error and Fatal Error #2 – Next Steps
83h System Event System Events Not applicable
3.4 Node Manager / ME Firmware owned Sensors (GID = 002Ch or 602Ch)
The following table can be used to find the details of sensors owned by the Node Manager / Management Engine (ME) firmware.
Table 8: Management Engine Firmware owned Sensors
Sensor
Number
Sensor Name Details Section Next Steps
17h ME Firmware Health Events ME Firmware Health Event ME Firmware Health Event – Next Steps
18h Node Manager Exception Events
Node Manager Exception Event
Node Manager Exception Event – Next Steps
19h Node Manager Health Events Node Manager Health Event Node Manager Health Event – Next Steps
1Ah
Node Manager Operational Capabilities
Change Events Node Manager Operational Capabilities
Change Node Manager Operational Capabilities Change – Next
Steps
1Bh
Node Manager Alert Threshold
Exceeded Events
Node Manger Alert Threshold Exceeded
Node Manger Alert Threshold Exceeded – Next Steps
