System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Linux* Kernel Panic Records
Revision 1.1 Intel order number G90620-002 131
Table 106: Linux* Kernel Panic String Extended Record Characteristics
Byte Field Description
1
2
Record ID ID used for SEL Record access
3 Record Type [7:0] – F0h = OEM non-timestamped, bytes 4-16 OEM defined
4 Slave Address The slave address of the card saving the panic
5 Sequence
Number A sequence number (starting at zero)
6
…
16 Kernel Panic Data These hold the panic sting. If the panic string is longer than 11 bytes, multiple messages will be sent with increasing sequence
numbers.
