System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Memory Subsystem
Revision 1.1 Intel order number G90620-002 75
Table 62: Sparing Redundancy State Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0033h = BIOS SMI Handler
11 Sensor Type 0ch = Memory
12 Sensor Number 11h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 0Bh (Generic Discrete)
14 Event Data 1 [7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset
0h = Fully Redundant
2h = Redundancy Degraded
15 Event Data 2 Location
[7:4] = Sparing Domain
0-3 = Channel A-D for Socket
[3:2] = Reserved
[1:0] = Rank on DIMM
0-3 = Rank Number
16 Event Data 3 Location
[7:5]= Socket ID
0-3 = CPU1-4
[4:3] = Channel
0-3 = Channel A-D for Socket
[2:0] = DIMM
0-2 = DIMM 1-3 on Channel
