Microsoft Windows* Records
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
128 Intel order number G90620-002 Revision 1.1
Byte Field Description
12
13
14
15
Shutdown Comment Shutdown Comment from the registry (LSB first):
HKLM/Software/Microsoft/Windows/CurrentVersion/Reliability/shutdown/Comment
16 Reserved 00h
14.3 Bug Check / Blue Screen Event Records
When the system experiences a bug check (blue screen), multiple records will be written to the event log. The first is a Bug Check /
Blue Screen OS Stop/Shutdown Event Record; this can be followed by multiple Bug Check / Blue Screen code OEM records that will
contain the Bug Check / Blue Screen codes. This information can be used to determine what caused the failure.
Table 103: Bug Check/Blue Screen – OS Stop Event Record Typical Characteristics
Byte Field Description
8
9
Generator ID 0041h – System Software with an ID = 20h
11 Sensor Type 20h = OS Stop/Shutdown
12 Sensor Number 00h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1 [7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset = 1h = Runtime Critical Stop (that is, “core dump”, “blue screen”)
15 Event Data 2 Not used
16 Event Data 3 Not used
