Power Subsystems
System Event Log Troubleshooting Guide for EPSD
Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
30
Intel order number G90620-002
Revision 1.1
Sensor
Number
Sensor Name
Next Steps
D4h
Baseboard +3.3V Auxiliary
(BB +3.3V AUX)
+3.3V AUX is supplied by the main board.
+3.3V AUX is used by the BMC, clock chips, PCI-E Slot, on-board NIC, Intel
®
C600 series Chipset, and
ICH.
1. Ensure all cables are connected correctly.
2. If the issue remains, replace the board.
3. If the issue remains, replace the power supplies.
D6h
Baseboard +1.05V Processor1 Vccp
(BB +1.05Vccp P1)
This 1.05V line is supplied by the main board.
This 1.05V line is used by processor 1.
1. Ensure all cables are connected correctly.
2. Check the processor is seated properly.
3. Cross test the processors. If the issue remains with the processor socket, replace the main board,
otherwise the processor.
D7h
Baseboard +1.05V Processor2 Vccp
(BB +1.05Vccp P2)
This 1.05V line is supplied by the main board.
This 1.05V line is used by processor 2.
1. Ensure all cables are connected correctly.
2. Check the processor is seated properly.
3. Cross test the processors. If the issue remains with the processor socket, replace the main board,
otherwise the processor.
D8h
Baseboard +1.5V P1 Memory AB
VDDQ
(BB +1.5 P1MEM AB)
This 1.5V line is supplied by the main board.
This 1.5V line is used by processor 1 memory slots A and B.
1. Ensure all cables are connected correctly.
2. Check the DIMMs are seated properly.
3. Cross test the DIMMs. If the issue remains with the DIMMs on this socket, replace the main
board, otherwise the DIMM.
D9h
Baseboard +1.5V P1 Memory CD
VDDQ
(BB +1.5 P1MEM CD)
This 1.5V line is supplied by the main board.
This 1.5V line is used by processor 1 memory slots C and D.
1. Ensure all cables are connected correctly.
2. Check the DIMMs are seated properly.
3. Cross test the DIMMs. If the issue remains with the DIMMs on this socket, replace the main
board, otherwise the DIMM.
