Sensor Cross Reference List
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
16 Intel order number G90620-002 Revision 1.1
Sensor
Number
Sensor Name Details Section Next Steps
2Ch
PCI Riser 2 Temperature
(PCI Riser 2 Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
2Dh
SAS Module Temperature
(SAS Mod Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
2Eh
Exit Air Temperature
(Exit Air Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
2Fh
Network Interface Controller
Temperature
(LAN NIC Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
30h –3Fh
Fan Tachometer Sensors
(Chassis specific sensor names)
Fan Tachometer Sensors Table 30: Fan Tachometer Sensor – Event Trigger Offset – Next Steps
40h –4Fh
Fan Present Sensors
(Fan x Present)
Fan Presence and Redundancy
Sensors
Table 32: Fan Presence Sensors – Event Trigger Offset – Next Steps
50h
Power Supply 1 Status
(PS1 Status)
Power Supply Status Sensors
Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next
Steps
51h
Power Supply 2 Status
(PS2 Status)
Power Supply Status Sensors
Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next
Steps
54h
Power Supply 1 AC Power Input
(PS1 Power In)
Power Supply Power In Sensors
Table 23: Power Supply Power In Sensor – Event Trigger Offset – Next
Steps
55h
Power Supply 2 AC Power Input
(PS2 Power In)
Power Supply Power In Sensors
Table 23: Power Supply Power In Sensor – Event Trigger Offset – Next
Steps
58h
Power Supply 1 +12V % of
Maximum Current Output
(PS1 Curr Out %)
Power Supply Current Out %
Sensors Table 25: Power Supply Current Out % Sensor – Event Trigger Offset –
Next Steps
59h
Power Supply 2 +12V % of
Maximum Current Output
(PS2 Curr Out %)
Power Supply Current Out %
Sensors Table 25: Power Supply Current Out % Sensor – Event Trigger Offset –
Next Steps
5Ch
Power Supply 1 Temperature
(PS1 Temperature)
Power Supply Temperature
Sensors Table 27: Power Supply Temperature Sensor – Event Trigger Offset – Next
Steps
