System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Microsoft Windows* Records
Revision 1.1 Intel order number G90620-002 125
Table 99: Boot up OEM Event Record Typical Characteristics
Byte Field Description
1
2
Record ID ID used for SEL Record access
3 Record Type [7:0] – DCh = OEM timestamped, bytes 8-16 OEM defined
4
5
6
7
Timestamp Time when the event was logged. LS byte first.
8
9
10
IPMI Manufacturer ID 0137h (311d) = IANA enterprise number for Microsoft
11 Record ID Sequential number reflecting the order in which the records are read. The numbers start at 1 for the first entry in
the SEL and continue sequentially to n, the number of entries in the SEL.
12
13
14
15
Boot Time Timestamp of when the system booted into the OS
16 Reserved 00h
