Cooling Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
56 Intel order number G90620-002 Revision 1.1
Table 44: Discrete Thermal Sensors Typical Characteristics
Byte Field Description
11 Sensor Type 01h = Temperature
12 Sensor Number See Table 45
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = See Table 45
14 Event Data 1 [7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 45
15 Event Data 2 Not used
16 Event Data 3 Not used
Table 45: Discrete Thermal Sensors – Next Steps
Sensor
Number
Sensor Name Event
Type
Event Trigger Offset Description Next Steps
Hex Description
0Dh SSB Thermal Trip 03h 01h State Asserted South Side Bridge (SSB) overheated 1. Check for clear and unobstructed
airflow into and out of the chassis.
2. Ensure the SDR is programmed and
correct chassis has been selected.
3. Ensure there are no fan failures.
4. Ensure the air used for cooling the
system is within the thermal
specifications for the system (typically
below 35°C).
90h P1 VRD Hot 05h 01h Limit Exceeded Processor 1 voltage regulator overheated
91h P2 VRD Hot Processor 2 voltage regulator overheated
92h P3 VRD Hot Processor 3 voltage regulator overheated
93h P4 VRD Hot Processor 4 voltage regulator overheated
94h P1 Mem01 VRD Hot Processor 1 Memory 0/1 voltage regulator
overheated
95h P1 Mem23 VRD Hot Processor 1 Memory 2/3 voltage regulator
overheated
96h P2 Mem01 VRD Hot Processor 2 Memory 0/1 voltage regulator
overheated
