Sensor Cross Reference List
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
22 Intel order number G90620-002 Revision 1.1
Sensor
Number
Sensor Name Details Section Next Steps
D2h
Baseboard +3.3V
(BB +3.3V)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D3h
Baseboard +5V Stand-by
(BB +5.0V STBY)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D4h
Baseboard +3.3V Auxiliary
(BB +3.3V AUX)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D6h
Baseboard +1.05V Processor1
Vccp
(BB +1.05Vccp P1)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D7h
Baseboard +1.05V Processor2
Vccp
(BB +1.05Vccp P2)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D8h
Baseboard +1.5V P1 Memory AB
VDDQ
(BB +1.5 P1MEM AB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D9h
Baseboard +1.5V P1 Memory CD
VDDQ
(BB +1.5 P1MEM CD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
DAh
Baseboard +1.5V P2 Memory AB
VDDQ
(BB +1.5 P2MEM AB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
DBh
Baseboard +1.5V P2 Memory CD
VDDQ
(BB +1.5 P2MEM CD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
DCh
Baseboard +1.8V Aux
(BB +1.8V AUX)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
DDh
Baseboard +1.1V Stand-by
(BB +1.1V STBY)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
DEh
Baseboard CMOS Battery
(BB +3.3V Vbat)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
