Install the RF Bandpass Filter inductors in the spaces provided
between relay K2 and frequency mixer Z1:
__L12 __L13
__L14
Install a jumper across the solder pads at W1 on the left side of the PCB
near the notch and electrolytic capacitor C60.
Carefully inspect the bottom of the PCB for the following:
All component leads are soldered. Be especially careful when
checking relays and other components with several leads to ensure
that all the leads are soldered. There will be some component
locations on the PCB that are not filled. This is normal. The same
RF PCB is used for the XV50, XV144 and XV222 transverters, and
some components are specific to each band.
All component leads are clipped at least as short as the relay leads.
Do not cut the relay pins.
Locate the male RCA plug. Solder a jumper between the center pin and
the shield. This plug will be used during the Alignment procedures.
This finishes Part II of the RF PCB Assembly. Proceed directly to RF PCB
Assembly Part III
