9
CHAPTER 1
Name Function
(20) Speed + / Speed -
To speed up movement of PTZ camera lens
To speed down movement of PTZ camera lens
(21) Focus + / Focus -
To focus in PTZ camera lens
To focus out PTZ camera lens
(22) Zoom + / Zoom -
To zoom in view of PTZ camera lens
To zoom out view of PTZ camera lens
1.2.4.1 To Set a Video Segment and Save
Keep a portion of the recorded video. Following the below steps to Set and Save the Wanted Portion of the
Recorded Video
1. While playback, press button and the A point of video segment is set. User should see the word “A-“on
upper right of surveillance screen.
2. Press again to set B point of video segment. User should see the word “A-B“ on upper right of
surveillance screen.
3. The DVR system will start repeat playback the video segment that user has set until user cancel the video
segment. Press again or right-click on playback screen will cancel the video segment.
4. To save the video segment, left-click on the channel screen that user wants to save to switch to single
screen mode.
5. And then, Plug in the pen drive device.
6. Click Segment button on Playback UI. The Output Video Clip dialog is displayed.
7. Click Save to output the video segment to USB storage device. Mark Include Player when backup option
to include the Qplayer application in output video segment folder for playback.
