121
CHAPTER 4
- Motion Recording
Start recording the video from the selected camera only when the system detects movement. Once a motion
is detected, the system automatically saves the previous frames and stop based on the Start Record Prior
and Stop Record After settings.
- Smart Recording
Automatically switch to recorded at the maximum frame rate setting once a motion is detected and if there is
no motion, it records at the minimum frame rate setting.
- No Recording
The system
won’t do any recording.
(3) Motion Detection
Adjust the sensitivity of the motion detection. The higher the value, the finer the sensitivity is detected. When it
detects a motion, a green triangle mark would appear at the upper left corner of the screen.
(4) Quality
Adjust the video quality. The higher the value, the lower the compression level and uses more hard disk space.
(5) Frame Rate
Set the maximum and minimum number of frames to be recorded during motion and motionless state. The
frame rate ranges from 01 to 30 for NTSC and 01 to 25 for PAL. The higher the frame rate, it uses more hard
disk space.
Always recoding frame rate is depending on max frame rate value.
(6) Video Size
Select the size of the video and click the  button. The higher the size, the larger the file it create.
(7) Individual Adjustment
Each camera can adjust video size and frame rate individually. Click Default will back to the factory default
value. The frame rate usage is shown in Used and Unused columns by CIF mode.
Adjusting video size and frame rate by channel, only available on the analog camera.
