109
CHAPTER 4
Name Function
(7) Remote setup Change the DVR server settings (see also Chapter 4.1.4 )
(8) Remote Emap To call out the Emap of remote DVR server to view.
(9) Remote Console Initiate Remote Console. It allows you to control DVR server (see also Chapter 4.2 ).
(10) Event Log Viewer Display the Event logs, Operation logs, System logs, and Network logs.
(11) 2-Way Audio Enable/disable 2-way audio function. This function allows the client and server to talk via
internet using MIC.
Make sure your microphone and speakers work before using this function. If the DVR server
Talk to web-
client setting is disabled, you won’t be able to hear from the other side.
(12) Split screen view Select from four different split screen types to view all the cameras.
(13) Auto Pan Group Operate the PTZ cameras automatically based on the selected camera group preset
position number.
(14) Camera preset
position number
Move the PTZ camera to the preset point.
(15) Direction buttons ’
moving speed
Adjust the moving speed of the PTZ camera lens. This speed will apply to the (18)
Direction buttons
’ moving speed only.
(16) Select PTZ Choose to enable/disable the PTZ camera. In the Select PTZ dialog box, Select column,
click to enable/disable viewing and controlling the PTZ camera.
Click OK to exit and save the setting and Cancel to exit without saving the setting.
(17) Atuo Pan Enable the PTZ cameras automatically based on the selected camera group preset position
number.
(18) Zoom +/- Zoom the image in or out.
(19) Focus +/- Adjust the focus manually to produce clear image.
(20) Direction Buttons Adjust and position the focal point of the PTZ camera. The supported direction buttons are
depended on the PTZ camera has supported.
