Chapter 3
The SCSI Interface
3. Insert one end of the unused SCSI cable into the top SCSI connector on the back
of Coolscan.
4. Connect the other end of the unused SCSI cable to the free SCSI connector of
the neighboring SCSI device.
5. Connect the SCSI terminator to the bottom SCSI connector on the back of
Coolscan.
It is equally possible to configure the SCSI chain with Coolscan in the center of
the chain. In this case, the SCSI terminator would reside on the optional device, as
opposed to Coolscan.
Please proceed to the section “Important Information About the SCSI
Interface.”
Setting Up the SCSI Chain - IS-10
The LS-10 can reside at any point in the SCSI chain. There are essentially two
possible SCSI chain configurations, the two SCSI devices configuration, and the multiple
SCSI devices configuration.
Connecting Two SCSI Devices
In the simplest case, only two SCSI devices share the SCSI chain - the SCSI host
and the SCSI target Ac\\ce. In our case, the SCSI host is the PC and the SCSI target
device is the scanner. This simple configuration is shown in Figure 3.15.
