Chapter 3 The SCSI Interfare
Please proceed to the section The PC’s External SCSI Connector.
SCSI Cables Used With the LS-10
The SCSI flat cable provided with the LS-10 enables you to connect the scanner
to the PC’s SCSI chain as either the only device on the SCSI bus, or as an additional
device. This is a chainable SCSI flat cable with two identical crimped connectors on
each end and one connector crimped in the center, as seen in Figure 3.6a.
If Coolscan is to be the last SCSI device in the SCSI chain; Connect one end
of this cable to the existing SCSI bus in the PC (connecting the SCSI cable to the PC’s
SCSI bus will be explained in the next section), then connect the opposite end to the
SCSI connector on the rear of Coolscan (refer to Figure 2.3 to locate the SCSI connec­
tor). The center connector is not used. Make sure that DIP switch #4 is in the termina­
tion ON position, as indicated in Figure 3.4.
If Coolscan is to be connected in the middle of the SCSI chain: Connect one
end of this cable to the existing SCSI bus (connecting the SCSI cable to the PC’s SCSI
bus will be explained in the next section), connect the center connector to the SCSI
connector on the rear of Coolscan, and connect the last connector to your internal disk
drive.
Nikon Coolscan Installation Guide for Windows Page 21
