COOLPIX 5000
EXTRAORDINARY DIGITAL
5.0
Effective Megapixels
Superhigh-precision
28-85mm
Zoom-Nikkor Lens
(35mm [135] equiv.)
1/4,000 sec.
Top Shutter Speed
3 Frames
Per Second
at Full Image Size
Durable
Magnesium
Alloy Body
Nikon Digital Camera COOLPIX 5000 Specifications
Type of camera Digital camera E5000
Effective pixels 5.0 million
CCD 2/3-inch-type CCD (total pixels: 5.24 million)
Image size 2,560 x 1,920 pixels,
UXGA-size (1,600 x 1,200), SXGA-size (1,280 x 960),
XGA-size (1,024 x 768), VGA-size (640 x 480),
3:2 (2,560 x 1,704) selectable
Lens 3x Zoom-Nikkor; f=7.1~21.4mm [35mm (135) format equivalent
to 28~85mm] /F2.8~4.8 with macro;
9 elements in 7 groups; all elements are made of environmentally
friendly glass; Nikon Super Integrated Coating (SIC) applied; three
glass molded aspherical lens elements included
Digital zoom Up to 4x
Autofocus Contrast-detect TTL AF;
7,514-step autofocus control including macro range;
5-Area Multi AF or Spot AF selectable
Focus modes 1) Continuous AF mode (when using LCD monitor),
2) Single AF mode (when not using LCD monitor and/or
selectable from shooting menu), 3) Manual (50 steps from 2cm
[0.8 in.] to infinity (
∞
) with Focus Confirmation Indication)
Focus range 50cm (19.7 in.) to infinity (
∞
);
2cm (0.8 in.) to infinity (
∞
) in Macro mode
Optical viewfinder Real-image zoom viewfinder; diopter adjustment: -2 ~ +1m -1
LCD monitor 1.8-in., 110,000-dot, low-temp. polysilicon TFT LCD (white LED
backlight);
brightness/hue adjustment; frame coverage: approx. 97%
Storage System: EXIF 2.1 file (uncompressed TIFF or compressed JPEG)
Design rule for Camera File system (DCF), Digital Print Order
Format (DPOF), QuickTime Motion JPEG (Movie)
Media: CF Card Type I/II, 512MB/1GB Microdrive™ Card
Number of frames with 32MB CF Card (approx.)
Image size FULL 3:2 UXGA SXGA XGA VGA
Image quality
HI 2 2 - - - -
FINE 13 14 32 50 75 173
NORMAL 26 28 62 95 139 289
BASIC 51 55 118 173 243 459
User setting 1) Automatic mode (default); Custom mode (three combinations of
mode setting can be memorized in #1-#3), 2) White Balance,
3) (Exposure) Metering, 4) Continuous (Shooting), 5) Best-Shot
Selector (BSS), 6) Image Adjustment (Auto/Normal/More Contrast/
Less Contrast/Lighten/Darken), 7) Saturation Control (-2 ~ +1/
Black & White), 8) Lens, 9) Exposure Options (AE Lock, Maximum
bulb duration 1 min./5 min.), 10) Focus Options, 11) Image
Sharpening, 12) Auto Bracketing, 13) Noise Reduction, Clear Image
Capture modes 1) Single,
2) Continuous H (3 fps; up to 3 frames),
3) Continuous L (1.5 fps),
4) Multi-Shot 16 (consecutive 16 frames at 3 fps),
5) High-speed Continuous (SXGA, XGA, VGA-size images; 3 fps),
6) Ultra High-speed Continuous (QVGA-size images; 30 fps;
number of frames selectable, up to 100 frames),
7) Movie with audio (QVGA-size images; 15 fps; up to 60 sec.)
Shutter Mechanical and charge-coupled electronic shutter;
1/4,000 (with minimum aperture) to 1 sec. in AUTO mode and
Programmed Auto; 1/4,000 to 8 sec. in Aperture-Priority
Auto; 1/2,000 to 8 sec. in Shutter-Priority Auto and Manual; Bulb
time limit (up to 5 minutes)
Aperture 7-blade iris diaphragm; 10 steps in 1/3 EV increments
Exposure control 1) Programmed Auto with Flexible Program [P],
2) Shutter-Priority Auto [S], 3) Aperture-Priority Auto [A],
4) Manual [M]; Exposure Compensation (±2 EV in 1/3 EV steps);
Auto Exposure Bracketing (3 or 5 frames within ±2 EV)
Exposure metering 4-mode TTL metering; 1) 256-segment Matrix [ ],
2) Center-Weighted [ ], 3) Spot [ ], 4) Spot AF Area [ ]
Exposure range EV -2.0 ~ +18.0 (W), EV -0.5 ~ +17.0 (T) (ISO 100 equivalent)
Sensitivity (approx.) ISO 100 equivalent; 100, 200, 400, 800, and Auto
(can be controlled in any exposure mode)
White balance 1) Matrix Auto White Balance with TTL control, 2) 5-mode
Manual with fine tuning (Fine/Incandescent/Fluorescent/Cloudy/
Speedlight), 3) Preset, 4) White Balance Bracketing
Self-timer 10 sec. or 3 sec. duration
Built-in Speedlight Guide number: 10 (when sensitivity is at ISO 100 equivalent)
Flash control: Sensor flash system
Flash modes: 1) Auto Flash, 2) Flash Cancel, 3) Anytime Flash,
4) Slow Sync, 5) Red-Eye Reduction
Accessory shoe Standard ISO 518; lock pin provided prevents Nikon Speedlight from
slipping off
External Speedlight Hotshoe connects to external Nikon Speedlight
SB-80DX/28DX/50DX/28/27/26/25/24/23/22s/30;
built-in Speedlight can be canceled when using external
Speedlight(s)
Playback menu options 1) 1 frame, 2) Thumbnail (4/9 segments), 3) Slide show,
4) Movie with audio, 5) Enlarged playback (up to 6x);
Shooting information; Histogram indication and highlight
point display; Hide and protect attributes can be set to
each image; Focus confirmation indication
Interface USB 1.1
I/O terminal Power input, Audio/Video output (NTSC or PAL selectable),
Digital terminal (USB 1.1/Remote Cord)
Power requirements One Rechargeable Li-ion Battery EN-EL1 (included),
One 6V 2CR5/DL245 lithium battery (optional),
Six 1.5V LR6 (AA-size alkaline) batteries* with Battery Pack
MB-E5000 (optional), AC adapter (optional)
*1.5V Lithium, 1.2V NiMH, or 1.2V NiCd batteries can also be used.
Battery life Approx. 100 min. when using LCD monitor and
EN-EL1 battery at normal temperature (20ºC [68ºF])
Dimensions (W x H x D) Approx. 101.5 x 81.5 x 67.5mm (4.0 x 3.2 x 2.7 in.)
Weight (without battery) Approx. 360g (12.6 oz.)
Accessories included* Lens cap, Camera strap, AV cable, CompactFlash™ Card,
USB cable UC-E1, Rechargeable Li-ion Battery EN-EL1,
Battery Charger, Nikon View 4 CD-ROM
Optional accessories Fisheye Converter FC-E8, Wideangle Converter WC-E68, Telephoto
Converter TC-E2, Telephoto Converter TC-E3ED**, Slide Copy
Adapter ES-E28***, Step Down Ring Lens Adapter UR-E5 and
UR-E6, Lens Hood HN-E5000, LCD Hood HL-E5000, Battery Pack
MB-E5000, Remote Cord MC-EU1
* Standard accessories may differ by country or area.
** Recommended for use with 1.2x digital zoom or higher
(vignetting occurs otherwise)
***Recommended for use with 1.4x digital zoom or higher
Driver Software Nikon View 4 System Requirements
Macintosh
OS Mac ® OS8.6 ~ 9.2
Models iMac™, iBook™, Power Macintosh ® G3 (Blue/White), Power Mac™ G4
or later, PowerBook ® G3 (only built-in USB ports supported) or later
RAM 32Mbyte (64Mbyte or more recommended)
Hard disk 15MB required for installation, with additional amount equivalent to twice the
capacity of the camera memory card required when Nikon View 4 is running
Display 640 x 480 with 16-bit color (800 x 600 or greater, full color recommended)
Others CD-ROM drive, USB interface (only built-in USB ports supported),
Mac
® OS8.6 needs USB driver (ver. 1.3.5) on Apple's website
Windows
OS/Models Windows ® 98/98SE, Windows ® 2000 Professional, Windows ® Me pre-installed
model
CPU MMX ® Pentium ® or later
RAM 64Mbyte (128Mbyte or more recommended)
Hard disk 15MB required for installation, with additional amount equivalent to twice the
capacity of the camera memory card required when Nikon View 4 is running
Display 640 x 480 with 16-bit color (800 x 600 or greater, full color
recommended)
Others CD-ROM drive, USB interface (only built-in USB ports supported)
