– IPv4 - Select to enter the library IP address with the IPv4 protocol.
– IPv6 - Select to enter four library IP addresses with the IPv6 protocol.
v Subnet Mask - If DHCP is disabled, set the IP address of the subnet mask.
– Subnet Mask - Select to enter the subnet mask address with the IPv4
protocol.
– Prefix Length - Select to enter the prefix length for the IPv6 protocol.
v Gateway - If DHCP is disabled, set the IP address of the gateway.
– IPv4 - Select to enter the gateway IP address with the IPv4 protocol.
– IPv6 - Select to enter four gateway IP addresses with the IPv6 protocol.
Configuring Operator Panel settings
Select Configuration > Configure Op Panel Settings to set the preferences when
with the Operator Panel.
Configure the Operator Panel with the following settings:
v Back light - Select to enable the LCD back light when with the Operator Panel.
– Input Count - If the auto back light is enabled, specify the time duration
before the back light turns OFF. The setting uses a four-digit timer in minutes.
v Login Password - Select to change the Operator Panel four-character login
password. The new password must be reentered for confirmation before the
password is changed (default: 0000).
Setting the library to factory defaults
Select Configuration > Set Default to reset the library to the factory default
settings. See Table 3-2 on page 3-10. The date and time must be reset after restoring
factory default settings. See “Configuring date and time settings” on page 4-11.
Important: This configuration setting deletes all current library settings, and
should be used with utmost caution.
Configuration
Configure Op Panel Settings
Configure LCD Back Light
Enable Auto Back Light
Input Count (min)
Disable Auto Back Light
Change Login Password
New Password
Reenter Password
Figure 4-22. Operator Panel settings
Configuration
Set Default
Figure 4-23. Factory default settings
Chapter 4. Operations 4-13
