The Operator Panel
Figure 4-1 shows the top-level menu tree structure of the Operator Panel on the
front of the TL1000 Tape Autoloader. For details on how to select commands and
options, see the description in “Operator Panel” on page 2-1.
Monitoring the library
Configuration settings
Use Configuration > View Settings to display a list of the library configuration
settings.
The settings that are displayed include:
v Library settings
– I/O station (On/Off)
– Auto cleaning (On/Off)
– Number of cleaning slots when Auto cleaning is enabled
– Operator Panel back light setting
v Network settings
– Link speed
– IP address protocol
– IPv4 settings (IP address, subnet mask address, gateway address, DHCP)
– IPv6 settings (IP address, gateway address, prefix length, DHCP, stateless
Auto configuration)
v Drive settings
– Model number
Top Level Commands Service Configuration
Unlock I/O Station*
Unlock Magazine
Commands
Configuration
View Current Information
Service
Logout
* If enabled.
Move Cartridge
Unload
Clean Drive
Inventory
Move to Ship Position
Reboot Drive
Reboot Library
Change Library State
Configure Library
Configure Auto Cleaning
Configure Network Settings
Configure Op Panel Settings
View Settings
Set Default
View Error Status
Diagnostics
View Firmware Revision
Telnet Service Port*
* For use by technical
support personnel only.
a29z006
4
Figure 4-1. Operator Panel top menus
Configuration
View Settings
Figure 4-2. Configuration settings
Chapter 4. Operations 4-3
|
