2. Insert the end of a straightened paper clip, or similar object, into the lock
release access hole. Gently push the lock mechanism to release the lock and
eject the cartridge magazine.
3. If the I/O station is enabled, push the lock mechanism twice or push and hold
the lock mechanism until the cartridge is withdrawn far enough to clear the
I/O station lock.
4. Remove the cartridge magazine from the front of the library. If the magazine is
stuck in the library and does not eject, see “Contacting Dell technical support”
on page 7-2
5. Examine the magazine and cartridges for damage.
v If there is damage to a cartridge, replace that cartridge.
v If there is damage to the magazine, replace the magazine.
Figure 8-1. Cartridge magazine lock release access hole
8-2 Dell PowerVault TL1000 Tape Autoloader User's Guide
|
|
