Chapter 8
Troubleshooting and Maintenance
8–11
Use the Program Memory test to verify the checksum of the current
application file.
1. Use the [NEXT] and [PREV] keys to display System Memory test on the
test selection screen.
DTAM Micro Diag Test
Program Memory
2. Press [ ] to initiate the test.
The DTAM Micro displays either a Pass or Fail message.
System Mem: pass
Press ENTER
3. Pressing [ ] terminates the Program Memory test.
The next test selection screen is displayed.
DTAM Micro Diag Test
Toggle Cntrl Signal
4. To terminate the test function , press the [NEXT] and [PREV] keys to
display Reset DUT in the test selection area. Press [ ] to reset the
terminal.
Program Memory Test
