Chapter 3
Initial Setup and Mode Menu

3–3

The powerup sequence is automatic, you do not have to respond to
the screens. The sequence depends upon DIP switch position #1 (upload /
download enable). The DTAM Micro is shipped with this switch On.

Powerup Sequence (DIP Switch #1 On)

1. The DTAM Micro verifies the system memory checksum, program

checksum, and system RAM. After the test is completed, the result is
displayed with the current DIP switch settings.

Memory Check: pass
DIP Switch: 101000

2. The display is tested, every pixel of the display is turned on.

ОО

If all of the pixels do not turn on, the display may be defective.

3. DTAM Micro information appears indicating the microprocessor core

firmware version and communication port (RS-232 or RS-485).

Operator Interface

Core: 3.00 RS-232

4. The DTAM Micro waits for an application download.

Programming Mode

Waiting Up/Download

Powerup Sequence (DIP Switch #1 Off)

1. The DTAM Micro verifies the system memory checksum, program

checksum, and system RAM. After the test is completed, the result is
displayed with the current DIP switch settings.

Memory Check: pass
DIP Switch: 101000

2. The display is tested, every pixel of the display is turned on.

ОО

If all of the pixels do not turn on, the display may be defective.

3. Operating system information appears indicating the firmware release

number and protocol being used (PLC5-DF1 or AB DH-485).

FRN 2.20 PLC5-DF1

4. The first application screen displays. If the DTAM Micro is being

powered up the first time you will see:

Bul. 2707 DTAM Micro

No Program Loaded

Powerup Sequence
