Rockwell Automation 2707-M232P3_M485P3 DTAM Micro Operator Interface Module User Manual
Page 43
Chapter 4
Transferring Applications
4–7
14. When the download is complete, you are returned to the Opening Menu.
and the DTAM Micro displays:
Programming Mode
Waiting Up/Download
15. Press [Esc] to exit the software.
16. Press [Y] to return to DOS.
The application is now loaded into the DTAM Micro. You can test the
application using the simulate function described in Chapter 3 or you can
run the application as described in Chapter 5.
Important: If you are running the application, make sure that you set the
DIP switch position #1 to the OFF position.
