Chapter 1
Using this Manual
1–2
No special knowledge is required to operate the DTAM Micro. If you are
installing the DTAM Micro, you must be familiar with the standard panel
cutout and installation techniques. If you are wiring the DTAM Micro, you
must be familiar with the electrical codes in your area (see inside front
cover).
You should be familiar with the DTAM Programming Software (see related
publications below).
This manual uses the following conventions:
•
Keys that you press on the DTAM Micro are enclosed in brackets [ ].
For example: [NEXT] refers to the NEXT key on the DTAM Micro.
•
References to menus are initial cap followed by the word Menu.
For example: Special Menu, Main Menu, Other Menu
•
All DTAM Micro displays are shown inside a rectangular box.
1 Reset 3 Special
2 Com-Port 4 Other
The following publications may be helpful for additional reference.
DTAM Micro Publications
Publication Number Title
2707-801
DTAM Programming Software Programming Manual
(Series J or later Software)
Wiring Publications
1770-6.2.2
Data Highway / Data Highway Plus / Data Highway-485
Cable Installation Manual
SLC Publications
Publication Number Title
1747-6.21
SLC 500 Fixed Hardware Style
Installation and Operation Manual
1747-UM011
SLC 500 Modular Hardware Style
Installation and Operation Manual
1747-RM001 SLC 500 Reference Manual
Intended Audience
Conventions
Related Publications
