Chapter 2
DTAM Micro Overview
2–12
The DTAM Micro is preset at the factory with the following defaults:
Operating System
The DTAM Micro is provided with a default application file:
•
RS-485 version has DH-485 operating system file
•
RS-232 version has PLC-5 DF1 operating system file
The application file displays a screen with the message:
Bul 2707 DTAM Micro
No Program loaded
DIP Switch Settings
The DTAM Micro is shipped with the following DIP Switch settings:
DIP Switch
Position
Default
Setting
Function
1 ON Upload/Download Enabled
2 OFF Master Security Disabled
3 ON Mode Key enabled
4 OFF Not Used
5 OFF Not Used
6 OFF Not Used
Operating Parameters
The following operating functions can be set using the DTAM Micro menu
functions. Refer to Chapter 3.
Default Value
Function Parameter
RS-485 Version RS-232 Version
Baud 19200 2400
C-Port Data Bits 8 8
Parity Even None
DTAM Micro Node 00 N/A
Special Max. Node 02 N/A
Controller Node 01 N/A
Simulate Off Off
Other Master Code 00000000 00000000
Scale On On
Default Settings
