Special Controller Functions
Appendix C
DTAM Micro
C–19
The Memory Transfer function allows the DTAM Micro to initiate a memory
transfer between a controller memory module and the controller.
•
Memory transfers with an SLC are bidirectional. Data can be transferred
to and from the memory module.
•
The PLC-5 only supports transfers from the PLC-5 to the memory
module.
SLC Controllers
1. Select item 3 from the Special Menu to access the Mem Xfer function.
You are prompted for a transfer direction:
1=SLC -> Mem Module
0 = Mem Module <- SLC
2. Place the memory module into the SLC.
3. Press [1] to transfer data from the SLC to the memory module.
Press [0] to transfer data from the memory module to the SLC.
You are returned to the Main Menu.
PLC-5 Controllers
1. Select item 2 from the Special Menu to access the Mem Xfer function.
The PLC-5 must be in Program or Remote Program mode or you will be
prompted:
Not in Program Mode
Press ENTER to exit
You are prompted to continue or abort the operation:
1=PLC -> Mem Module
0 = Abort
2. Place the memory module into the PLC.
3. Press [1] to transfer data from the PLC to the memory module.
Press [0] to abort the operation.
You are returned to the Main Menu.
Using the Memory
Transfer Function
