A–B
6
Chapter
6–1
Installation
This chapter contains the following sections:
Section Page
Safety Guidelines 6–1
Operating Environment 6–1
Enclosures 6–2
Equipment Required 6–3
Clearances 6–3
Mounting Dimensions 6–4
Cutout Template 6–5
Installation 6–6
Connecting AC Power 6–7
Install the DTAM Micro terminal using publication NFPA 70E, Electrical
Safety Requirements for Employee Workplaces as a guide.
In addition, grounding is an important safety measure in electrical
installations. A source for grounding recommendations is the National
Electrical Code published by the National Fire protection Association of
Boston Massachusetts.
Be certain to follow all directions for installing and connecting DC power to
the DTAM Micro.
When used in a hazardous environment, the ultimate enclosure must be in
accordance with Class 1, Division 2 wiring methods as described in the
National Electrical Code (ANSI/NFPA 70) and the Canadian Electrical Code.
All peripheral equipment must be suitable for the location in which it is used.
Use only a Class 2 power source as described in the National Electrical Code
(ANSI/NFPA 70) and Canadian Electrical Code. The recommended AC to
DC adapters (Catalog No. 1747-NP1 and Catalog No. 1747-NP2) meet this
requirement.
The DTAM Micro contains no user serviceable parts.
Objectives
Safety Guidelines
