Chapter 3
Initial Setup and Mode Main
3–4
Access the Mode Menu by pressing the [MODE] key. All other functions are
halted when the menu is displayed.
Note: DIP switch SW-3 must be in the On position or the [MODE] key will
not function.
The Mode Menu provides access to four functions:
1 Reset 3 Special
2 Com-Port 4 Other
Select a menu item by pressing the corresponding numeric key [1]
! [4].
The menu structure is shown below:
Resets the DTAM Micro
Configures DTAM Micro
Communications Port
Special
Controller Operations
Sets Master
Security Code ➀
Enables / Disables
Scaling
Simulates Controller
Communications
Performs
Functional Tests
Exits to
Mode Menu
1 Reset 3 Special
2 Com-Port 4 Other
1 Baud Rate 3 Parity
2 Data Bits 4 Exit
1 P-A/D 3 Mem Xfer
2 Mode 4 Clr Fault
1 Master 3 Simulate
2 Scale 4 Test 5 Ex
➀ DIP switch position 2 must be On (master code enable).
SLC or 50X Address
1 = Edit Addr
0 = Bypass
(Only with DH485
Operating System)
Mode Menu
