Special Controller Functions
Appendix C
DTAM Micro
C–10
To read/write the contents of controller Control files:
1. Select item 1 from the Special Menu to access the P–A/D function.
You are prompted for a file type:
Select File Type:
(O) Output
2. Press [NEXT] and [PREV] keys to scroll through the file types.
Select Control and press [ ].
You are prompted for a file number:
Select File Num=_____
3. Enter a file number (3-999 for PLCs or 3-7, 9-255 for SLCs) and press
[ ].
You are prompted for an element number:
Select File Num=006
Elem= _____
4. Enter the element number. If you are accessing PLC-5 data, you must
enter an octal value.
You are shown the length value
File=R006 Len
Elem=002 100
Length
Value
5. Press [NEXT] to display the position value:
File=R006 Pos
Elem=002 25
Position
Value
Reading / Writing Controller
Control Files
