To read/write the contents of controller Timer files:

1. Select item 1 from the Special Menu to access the P–A/D function.

You are prompted for a file type:

Select File Type:
(O) Output

2. Press [NEXT] and [PREV] keys to scroll through the file types.

Select Timer and press [

You are prompted for a file number:

Select File Num=_____

3. Enter a file number (3-999 for PLCs or 3-7, 9-255 for SLCs) and

press [

You are prompted for an element number:

Select File Num=102
Elem= _____

4. Enter the element number. If you are accessing PLC-5 data, you must

enter an octal value.

You are shown the timer accumulator value

File=T102

Acc

Elem= 008

120

Accumulator

Accumulated Value

5. Press [NEXT] to display the timer preset value:

File=T102

Pre

Elem= 008

200

Preset

Preset Value

Reading / Writing Controller
Timer Files
