72 1794-IF8IH and 1794-OF8IH Configuration
HART Status Fields
The 1794-OF8IH module supports two connections for pass through
messages. Pass through messages provide the ability to send HART messages
to the HART device by passing through the I/O Module. In additional, HART
device information automatically gathered by the I/O module may be accessed
through this interface.
0x44
Channel 4
Format Configuration Error
0x45
Channel 5
Format Configuration Error
0x46
Channel 6
Format Configuration Error
0x47
Channel 7
Format Configuration Error
0x50
Channel 0
Data out of range
0x51
Channel 1
Data out of range
0x52
Channel 2
Data out of range
0x53
Channel 3
Data out of range
0x54
Channel 4
Data out of range
0x55
Channel 5
Data out of range
0x56
Channel 6
Data out of range
0x57
Channel 7
Data out of range
0x80
Module
Hardware Failure
0x90
Channel 0
Calibration Error
0x91
Channel 1
Calibration Error
0x92
Channel 2
Calibration Error
0x93
Channel 3
Calibration Error
0x94
Channel 4
Calibration Error
0x95
Channel 5
Calibration Error
0x96
Channel 6
Calibration Error
0x97
Channel 7
Calibration Error
0xA0
Channel 0
Internal Bus Com Error
0xA1
Channel 1
Internal Bus Com Error
0xA2
Channel 2
Internal Bus Com Error
0xA3
Channel 3
Internal Bus Com Error
0xA4
Channel 4
Internal Bus Com Error
0xA5
Channel 5
Internal Bus Com Error
0xA6
Channel 6
Internal Bus Com Error
0xA7
Channel 7
Internal Bus Com Error
Diagnostic Status Value: 0
Channel
Failure
