Publication 1794-UM065B-EN-E - September 2010
142 Use the 1794-OF8IH Module with the Generic Profile
Output
Refer to the following tables for output information.
Digital Data
Fault Reset
Analog Data
5
[Adapter Name]:[Slot]:C.Data[17].5
6
[Adapter Name]:[Slot]:C.Data[17].6
7
[Adapter Name]:[Slot]:C.Data[17].7
Disable Mode
Bit 0
False
0
True
1
Channel
Word
Channel
Words
0
[Adapter Name]:[Slot]:O.Data[0].0
1
[Adapter Name]:[Slot]:O.Data[0].1
2
[Adapter Name]:[Slot]:O.Data[0].2
3
[Adapter Name]:[Slot]:O.Data[0].3
4
[Adapter Name]:[Slot]:O.Data[0].4
5
[Adapter Name]:[Slot]:O.Data[0].5
6
[Adapter Name]:[Slot]:O.Data[0].6
7
[Adapter Name]:[Slot]:O.Data[0].7
Bits
0
[Adapter Name]:[Slot]:C.Data[0].15
Channel
Bits
0
[Adapter Name]:[Slot]:O.Data[1]
1
[Adapter Name]:[Slot]:O.Data[2]
2
[Adapter Name]:[Slot]:O.Data[3]
