122 Use the 1794-IF8IH Module with the Generic Profile
4 [Adapter Name]:[Slot]:C.Data[3].0
[Adapter Name]:[Slot]:C.Data[3].1
[Adapter Name]:[Slot]:C.Data[3].2
[Adapter Name]:[Slot]:C.Data[3].3
5 [Adapter Name]:[Slot]:C.Data[3].4
[Adapter Name]:[Slot]:C.Data[3].5
[Adapter Name]:[Slot]:C.Data[3].6
[Adapter Name]:[Slot]:C.Data[3].7
6 [Adapter Name]:[Slot]:C.Data[3].8
[Adapter Name]:[Slot]:C.Data[3].9
[Adapter Name]:[Slot]:C.Data[3].10
[Adapter Name]:[Slot]:C.Data[3].11
7 [Adapter Name]:[Slot]:C.Data[3].12
[Adapter Name]:[Slot]:C.Data[3].13
[Adapter Name]:[Slot]:C.Data[3].14
[Adapter Name]:[Slot]:C.Data[3].15
Channel Bits
Channel Data Formats
Format
(1) Bits Format Name Signal Range User Range Resolution
15 14 13 12
11 10 9 8
7 6 5 4 LO HI LO HI
3 2 1 0
0 0 0 0 0 0…20 mA in Milliamps 0.00 22.00 0
(0.000 mA) 22000
(22.000 mA) 1.0 µA
1 0 0 0 1 0…20 mA in % Full Scale 0.00 22.00 0
(0%) 11000
(110.00%) 2.0 µA
3 0 0 1 1 0…20 mA in UINT 0.00 20.00 0 65535 0.3052 µA
4
(2) 0 1 0 0 4…20 mA in Milliamps 2.00 22.00 2000
(2.000 mA) 22000
(22.000 mA) 1.0 µA
5
(2) 0 1 0 1 4…20 mA in % Full Scale 2.00 22.00 -1250
(-12.50%) 11250
(112.50%) 1.6 µA
7
(2) 0 1 1 1 4…20 mA in UINT 4.00 20.00 0 65535 0.2441 µA
(1) All other formats are invalid.
(2) HART Communications supported with these data formats only.
