Additional HART Protocol Information 103
Start Character
The start character of a HART message indicates the frame’s format, the
source of the message, and if it is using burst mode.
HART Address
The Smart Transmitter Interface addresses HART field devices using either a
short or long frame address format, as specified by the HART delimiter byte.
A short frame address is one byte long. A long frame address is five bytes long
and includes a unique 32-bit identifier encoded within each field device by the
manufacturer.
HART field device addressing is device dependent. Some devices do not
support long frame addressing while others only recognize short frame
addressing for HART Command 0. In this situation, use HART Command 0
to determine the long frame address, and then use long frame addressing for al
other HART commands. Refer to the documentation provided with your field
device for details about the addressing formats it supports.
HART Command
This one-byte field specifies the HART command that is to be sent by the
Smart Transmitter Interface to the field device. Many commands are device
dependent. Refer to the documentation provided with your field device for
details about the commands supported. Set this field to a device-recognizable
command before sending the packet to the Smart Transmitter Interface.
Start Character Byte Definitions
Frame Type
Short Frame Addressing
(hex)
Long Frame Addressing
(hex)
Master To Slave
02
82
Slave To Master
06
86
Burst Mode From Slave
01
81
Representative of HART Universal Commands
Universal Command
(dec)
Description
Expected Response
0
Read unique indentifier
Unique 32-bit device indentifier,
revision levels, number of
preambles required
1
Read primary variable
Primary variable in floating point
(IEEE 754 format)
2
Read primary variable
current and percent of range
Primary variable in milliamperes
and percents
