32 1794-IF8IH and 1794-OF8IH Configuration
1794-IF8IH I/O Profile
All Allen Bradley FLEX I/O modules have a sixteen word table of Real Time
Data (RTD) to be transferred between the controller and the I/O module.
Not all 16 words need be allocated. The IF8IH has the following RTD IO
Profile:
In addition to the RTD, the module uses EDT for Configuration and HART
data. The IF8IH has the following EDT IO Profile:
Configuration Parameters
The configuration is shown in the table below. These are normal module
configuration items and are sent to the module. Configuration is located at
EDT assembly 37.
RTD Index
Assembly/Index
Asembly
RTD 0
MSW
Module Status Word
RTD 1
EDT Read Word
EDT Read Word
RTD 2…9
I:0…I:7
RTD Input Data
RTD 10…14
S:0…14
RTD Input Data
RTD 15
EDT Write Word
EDT Write Word
Nunmber of Word EDT Assembly
42
EDT Configuration Data
98
Cyclic EDT HART Input Data (Accessed in eight 24 byte Assemblies)
48
EDT Output Pass-Through message request buffer A
48
EDT Output Pass-Through message request buffer B
48
EDT Input Pass-Through message request buffer A
48
EDT Input Pass-Through message request buffer B
Configuration Parameters
Word
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
R
R
F7
F6
F5
F4
BOB
(1)
R
R
F3
F2
F1
F0
BOA
(1)
1
DH7
DH6
DH5
DH4
DH
3
DH2
DH1
DH0
Reserved
(2)
2
CH 3 Format
CH 2 Format
CH 1 Format
CH 0 Format
3
CH 7 Format
CH 6 Format
CH 5 Format
CH 4 Format
4
CH1 HART Current Ratio
FLTR1
CH0 HART Current Ratio
FLTR0
