1794-IF8IH and 1794-OF8IH Configuration 45
Real Time Data (RTD)
Profile, Primary Input
Parameters
Primary Input Data (8 of 16 bits each)
Specifies the value of the input data from the module. Specific format is
controlled by module Data Format Control parameter.
Range: Refer to Data Format (8 of 4 bits) on page 39.
Data Table Reference: input data, Input Words 0…7 (I0…I7), bits 0…15.
Input Map
Word
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
Channel 0 Input Data
1
Channel 1 Input Data
2
Channel 2 Input Data
3
Channel 3 Input Data
4
Channel 4 Input Data
5
Channel 5 Input Data
6
Channel 6 Input Data
7
Channel 7 Input Data
8
H7
H6
H5
H4
H3
H2
H1
H0
L7
L6
L5
L4
L3
L2
L1
L0
9
R7
R6
R5
R4
R3
R2
R1
R0
P7
P6
P5
P4
P3
P2
P1
P0
10
11
C7
C6
C5
C4
C3
C2
C1
C0
F7
F6
F5
F4
F3
F2
F1
F0
12
X7
X6
X5
X4
X3
X2
X1
X0
Reserved
Where:
Hn: Channel n High Alarm
Ln : Channel n Low Alarm
Rn : Channel n Out of Range Alarm
Pn : Channel n Second (Remote) Alarm
Fn : Channel n HART Failure
Cn : Channel n HART Current Fault
Xn : Channel n HART Transmitter Present
