7
Publication 1794-UM065B-EN-E - September 2010
Chapter
2
Configurable FLEX I/O Analog Module
Features
Overview
Read this chapter to familiarize yourself with configurable features on the
input and output analog modules
HART configurable features described in this chapter include the following
Topic
Page
Select Your Analog Input Module Operating
Features
Select Your Analog Output Module Operating
Features
Understand Image Table Mapping and Bit/Word
Descriptions
Analog/Digital Configurable Features on FLEX I/O Analog I/O Modules
1794-IF8IH Input Module
1794-OF8IH Output Module
Fault Mode
Output Enable
High Low Error Level
Module Fault State Mode
Input Filter Cutoff
Local Fault Mode
Data Format
Data Format
Global Reset
Analog Fault State
Latch Retry Mode
Fault Alarm
IMPORTANT
You must use the I/O configuration portion of your PLC programming
software to select and configure these features. This manual assumes
familiarity with the programming software. A brief description of
each module feature is provided here. For more information on your
programming software, refer to the software user manual.
