Publication 1794-UM065B-EN-E - September 2010
Use the 1794-IF8IH Module with the Generic Profile 121
HART Disable
Channel Data Format
Channel Bits
0 [Adapter Name]:[Slot]:C.Data[1].8
1 [Adapter Name]:[Slot]:C.Data[1].9
2 [Adapter Name]:[Slot]:C.Data[1].10
3 [Adapter Name]:[Slot]:C.Data[1].11
4 [Adapter Name]:[Slot]:C.Data[1].12
5 [Adapter Name]:[Slot]:C.Data[1].13
6 [Adapter Name]:[Slot]:C.Data[1].14
7 [Adapter Name]:[Slot]:C.Data[1].15
Disable Mode Bit 0
False 0
True 1
Channel Bits
0 [Adapter Name]:[Slot]:C.Data[2].0
[Adapter Name]:[Slot]:C.Data[2].1
[Adapter Name]:[Slot]:C.Data[2].2
[Adapter Name]:[Slot]:C.Data[2].3
1 [Adapter Name]:[Slot]:C.Data[2].4
[Adapter Name]:[Slot]:C.Data[2].5
[Adapter Name]:[Slot]:C.Data[2].6
[Adapter Name]:[Slot]:C.Data[2].7
2 [Adapter Name]:[Slot]:C.Data[2].8
[Adapter Name]:[Slot]:C.Data[2].9
[Adapter Name]:[Slot]:C.Data[2].10
[Adapter Name]:[Slot]:C.Data[2].11
3 [Adapter Name]:[Slot]:C.Data[2].12
[Adapter Name]:[Slot]:C.Data[2].13
[Adapter Name]:[Slot]:C.Data[2].14
[Adapter Name]:[Slot]:C.Data[2].15
