Hart current fault – Rockwell Automation 1794-OF8IH FLEX Isolated Input/Output HART Analog Modules User Manual
Page 157

Publication 1794-UM065B-EN-E - September 2010
Use the 1794-OF8IH Module with the Generic Profile 145
HART Current Fault
0x94
Channel 4
Calibration Error
0x95
Channel 5
Calibration Error
0x96
Channel 6
Calibration Error
0x97
Channel 7
Calibration Error
0xA0
Channel 0
Internal Bus Com Error
0xA1
Channel 1
Internal Bus Com Error
0xA2
Channel 2
Internal Bus Com Error
0xA3
Channel 3
Internal Bus Com Error
0xA4
Channel 4
Internal Bus Com Error
0xA5
Channel 5
Internal Bus Com Error
0xA6
Channel 6
Internal Bus Com Error
0xA7
Channel 7
Internal Bus Com Error
Module Diagnostic Status Range
Diagnostic Status Value: 0
Channel
Failure
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[3].8
1
[Adapter Name]:[Slot]:I.Data[3].9
2
[Adapter Name]:[Slot]:I.Data[3].10
3
[Adapter Name]:[Slot]:I.Data[3].11
4
[Adapter Name]:[Slot]:I.Data[3].12
5
[Adapter Name]:[Slot]:I.Data[3].13
6
[Adapter Name]:[Slot]:I.Data[3].14
7
[Adapter Name]:[Slot]:I.Data[3].15
Fault
Bit 0
False
0
True
1
