Use the 1794-OF8IH Module with the Generic Profile 143
Input
Refer to the following tables for input information.
Diagnostic Status
Module Diagnostic Status (1 of 8 bits)
3
[Adapter Name]:[Slot]:O.Data[4]
4
[Adapter Name]:[Slot]:O.Data[5]
5
[Adapter Name]:[Slot]:O.Data[6]
6
[Adapter Name]:[Slot]:O.Data[7]
7
[Adapter Name]:[Slot]:O.Data[8]
Channel
Bits
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[0].0
1
[Adapter Name]:[Slot]:I.Data[0].1
2
[Adapter Name]:[Slot]:I.Data[0].2
3
[Adapter Name]:[Slot]:I.Data[0].3
4
[Adapter Name]:[Slot]:I.Data[0].4
5
[Adapter Name]:[Slot]:I.Data[0].5
6
[Adapter Name]:[Slot]:I.Data[0].6
7
[Adapter Name]:[Slot]:I.Data[0].7
Module Diagnostic Status Range
Diagnostic Status Value: 0
Channel
Failure
0x00
All
No Errors (default)
0x10
Channel 0
HART Iloop Threshold Configuration Error
0x11
Channel 1
HART Iloop Threshold Configuration Error
0x12
Channel 2
HART Iloop Threshold Configuration Error
0x13
Channel 3
HART Iloop Threshold Configuration Error
0x14
Channel 4
HART Iloop Threshold Configuration Error
0x15
Channel 5
HART Iloop Threshold Configuration Error
0x16
Channel 6
HART Iloop Threshold Configuration Error
0x17
Channel 7
HART Iloop Threshold Configuration Error
0x20
Channel 0
Remote/Local Alarm Configuration Error
