Publication 1794-UM065B-EN-E - September 2010
Use the 1794-OF8IH Module with the Generic Profile 139
2 [Adapter Name]:[Slot]:C.Data[5].3
[Adapter Name]:[Slot]:C.Data[5].4
[Adapter Name]:[Slot]:C.Data[5].5
[Adapter Name]:[Slot]:C.Data[5].6
[Adapter Name]:[Slot]:C.Data[5].7
3 [Adapter Name]:[Slot]:C.Data[5].11
[Adapter Name]:[Slot]:C.Data[5].12
[Adapter Name]:[Slot]:C.Data[5].13
[Adapter Name]:[Slot]:C.Data[5].14
[Adapter Name]:[Slot]:C.Data[5].15
4 [Adapter Name]:[Slot]:C.Data[6].3
[Adapter Name]:[Slot]:C.Data[6].4
[Adapter Name]:[Slot]:C.Data[6].5
[Adapter Name]:[Slot]:C.Data[7].6
[Adapter Name]:[Slot]:C.Data[7].7
5 [Adapter Name]:[Slot]:C.Data[7].11
[Adapter Name]:[Slot]:C.Data[7].12
[Adapter Name]:[Slot]:C.Data[7].13
[Adapter Name]:[Slot]:C.Data[7].14
[Adapter Name]:[Slot]:C.Data[7].15
6 [Adapter Name]:[Slot]:C.Data[8].3
[Adapter Name]:[Slot]:C.Data[8].4
[Adapter Name]:[Slot]:C.Data[8].5
[Adapter Name]:[Slot]:C.Data[8].6
[Adapter Name]:[Slot]:C.Data[8].7
7 [Adapter Name]:[Slot]:C.Data[8].11
[Adapter Name]:[Slot]:C.Data[8].12
[Adapter Name]:[Slot]:C.Data[8].13
[Adapter Name]:[Slot]:C.Data[8].14
[Adapter Name]:[Slot]:C.Data[8].15
HART Current Ratio
Channel Bits
