Rockwell Automation 2098-DSD-xxx Ultra3000 Host Commands for Serial Interface - Manual (Page 81)

Publication 2098-RM003A-EN-P October 2001
Command Reference 2-65
Motor Resistance
Motor Inductance
Format: :aa03Dfddddcc
Parameter
Code: 0x03D
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x04 = Data Below Minimum
0x08 = Invalid Function Code
Data Fields: dddd Phase-phase stator resistance, in units of Ohms *
256.
Minimum
Value: 0x0001
Maximum
Value: 0xFFFF
Default: 998
Format: :aa03Efddddcc
Parameter
Code: 0x03E
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x04 = Data Below Minimum
0x08 = Invalid Function Code
Data Fields: dddd Phase-phase stator inductance, in units of
milliHenries * 256.
Minimum
Value: 0x0001
Maximum
Value: 0xFFFF
Default: 6144
