Page 21: Position window size position window time
Publication 2098-RM003A-EN-P October 2001
Command Reference
2-5
Position Window Size
Position Window Time
Format:
:aa016fddddddddcc
Parameter
Code:
0x016
Valid Function
Codes:
0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes:
0x03 = EEPROM Write Error
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields:
dddddddd
Position window size, in units of counts.
Minimum
Value:
0x00000000
Maximum
Value:
0x7FFFFFFF
Default:
20
Format:
:aa017fddcc
Parameter
Code:
0x017
Valid Function
Codes:
0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes:
0x03 = EEPROM Write Error
0x08 = Invalid Function Code
Data Fields:
dd
Position window time, in units of milliseconds.
Minimum
Value:
0x00
Maximum
Value:
0xFF
Default:
20
